According to Hall Effect principle, when a conductor or semiconductor with current flowing in one direction is introduced perpendicular to a magnetic field, a voltage could be measured at right angles to the current path. Open the app and set up a New Project. refrence code, Measuring Water Usage with NodeMCU +WaterFlow Sensor. To review, open the file in an editor that reveals hidden Unicode characters. One question. Inside the void setup(), define the water flow sensor pin as input pull-up. esptool.py v2.4[], I am trying to flash an ESP12-F, I have downloaded[], Adding some background. Stay Informed - Subscribe to our Newsletter. Now that the Gerber File has been uploaded, you can order from the website. terimaksih. by grovkillen 21 May 2019, 10:46, #3 That's 159 per 10 seconds (which is the interval you have). Hi, #define SENSOR D3 +FUgvt (ZwQ00c 30 v4|3*ERaWt}.+wYXzB T3 In the last two days i have been workin on this sensor. So sign in to yourThinger.ioaccount and follow the below steps to connect your device. flowRate = ((1000.0 / (millis() - previousMillis)) * pulse1Sec) / calibrationFactor; Similarly, the ESP8266s D2 and D1 are linked to the SDA and SCL pins of the I2C OLED Display, respectively. Cut power completely to the ESP8266 and other parts by code? Post who will be happy to help. Post The interrupt function will be calling the pulseCounter() function. ConclusionI hope all of you understand how to design IoT Water Flow Meter using ESP8266. Hi. I increased deepSleep during night time where no-one takes shower, during day-time it wakes up every 3min though, removed the LCD screen, removed OTA). A cheap water flow meter is therefore necessary. pinMode(SENSOR, INPUT_PULLUP); It's powered by a recycled 18650 circa 1300mAh In a 5V UPS holder. ScienceDirect is a registered trademark of Elsevier B.V. Click here to go back to the article page. The water flow rate and total volume of water passed through the pipe will be displayed on the OLED Display. The VCC (Red Wire) and GND (Black Wire) pins of flow sensors are connected to 5V and GND pins of NodeMCU while the Signal pin (Yellow Wire) is connected to D4 pin of NodeMCU. byte pulse1Sec = 0; Change the Wifi SSID, password, and Thingspeak API key from the line above. WiFi login and MQTT (if no water is running obviously), is there anything in the code that would use too much power? by mrc-core 21 May 2019, 11:10, #4 Serial.print("L/min"); #define DEVICE_ID "Device-ID" Adafruit SHT40 Temperature and Humidity Sensor Board integrates a fourth-generation sensorand is designed with a true I2C interface. For PCB & PCBA Services, the majority of consumers rely on NextPCB for this reason. In the attachInterrupt() function, it is specified that SENSOR is the external interrupt pin, and pulseCounter function is called whenever a pulse is received. Post by mrc-core 21 May 2019, 15:01, #10 R[], Hi I'm trying to build a water counter on my house using a node mcu esp8266 and a SEN-HZ43WB g3-4 here's the link for the water flow i have: One other thing i have done on the formula was this: %value%*60/477 i did get some values but i dont believe they are rigth. If you have a problem obtaining your download, click #1 previousMillis = millis(); When I upload this code, the serial monitor shows "ISR not in IRAM" error. Thinger.io is an Open-Source Platform for the Internet of Things. Someone did tell me you can cut one of the traces on the D1 mini to disconnect the voltage regulator and USB, reducing power leakage even further, but I'm now using bare ESP8266-MOD modules rather that D1 Minis and powering them straight into the 3.3v pin from the the batteries. I need the Wi[], I have an application built with ESP_RTOS_SDK ver[], While flashing, I am seeing this: On the esp easy log e get values like this: You zero the counter at the end of the set interval. My code (without detailed includes which only include several variables): Also have you looked at the ESP-Now protocol for the ESP82566 instead of WIFi? Here we are explaining some important parts. I've updated arduion to the latest version (1.18.13) but I'm having no luck. How can I resolve this error ?? Here's one on modifying WeMos D1 for long battery https://www.youtube.com/watch?v=rfPwOtoGO4E, One immediate thought is to power off the flow sensor while sleeping, I now switch power to the capacitive soil moisture sensors for my greenhouse unit which tripled it's runtime. After that, define the pin where you connected the Water Flow Sensor. The flow rate and volume vary slightly based on the flow rate, fluid pressure, and sensor orientation, making this sensor the best and cheapest one but not the most precise. volatile byte pulseCount; Copied the API Key. Ranging from control of heating equipment, flow sensing, floor temp sensing, energy calculation, floor thermostat, water usage, to an interactive "fun box" for my grandson. by mrc-core 21 May 2019, 11:14, #5 Post Although there are a lot of water flow sensors on the market, they are too pricey for most people to use and afford. #include The flow sensor is okay I have checked it. Below is a list of the source codes entirety. Hi, i have uploaded the sketch and done the SSID/Password changes. Thats all; your device is ready to connect. Lets get to the programming section now. Please guide me about this error. Space farming using food computers for sustainable farming, A light bulb switch using NodeMCU and the Blynk app, Controlling a Centurion gate Motor with NodeMCU a 2-channel relay, Read and display the water flow sensor on Blynk. It provides every needed tool to prototype, scale, and manage connected products in a very simple way. How would this work though as when I look into the water flow meters pulses it seems it sends a value (even if 0) every second or so, this would the reset the chip every time, no? After that, we need to define some variables to hold the values. anywhoelse attachInterrupt(digitalPinToInterrupt(SENSOR), pulseCounter, FALLING);

Hi again now that i'm at home i can do some testings. The water flow sensor has three wires, i.e. What you should do is go into the longest possible deep sleep and only be woken up by the flow meter pulses. by grovkillen 21 May 2019, 12:22, #7 The circuit diagram for the IoTWater Flow Meter is given below. currentMillis = millis(); A few more questions on the power leakage: - When the Wemos D1 is in deepsleep, I assume that the water flow sensor also gets no power? WHOOP 4.0 Uses Nordics SoC to Supervise Sensors and Relay Data to Smartphone App, New LTE-M Module with an eSIM offers Secure Solution to Connect Size-Constrained IoT Applications to the Cellular Network, Aistin Level and Aistin Motion Devices use Nordic nRF9160 SiP to Relay Sensor Data to Cloud Platform, Outdoor Wideband Log Periodic Directional Antennas for DAS, 4G and 5G Networks, Raspberry Pi Pico W Brings Wi-Fi to IoT for just 6$, Won't compile - expected initializer beforepulseCounter(), Littelfuse SC1103C-01UTG Bidirectional TVS Diode, Cypress Semiconductor IoT Sense Expansion Kit, TE Connectivity Multi-Band GNSS Ceramic Antennas, Analog Devices Inc. DC3024A Demonstration Circuit for LT4200, Microchip Technology PIC18F16Q40 Curiosity Nano Kit (EV70C97A), Vishay / Dale CRCW-P Thick Film Chip Resistors, Adafruit SHT40 Temperature & Humidity Sensor Board. jadi nilai kalibrasinya berapa? Here are the results: New testings, after a reboot i did see a value off 1L on domoticz dummy counter. The complete code for sending data to Thinger.io is given at the end of the page. NodeMCU has built-in pull-up resistors that can be accessed by setting the pinMode() as INPUT_PULLUP. The tiny Water Flow Meter board can be made using a specially designed PCB. I don't know about your IDE version, but[], Hey there everyone; You're better off powering the 3.3V pin directly if you can. #define USERNAME "Your Account Username" } Press question mark to learn the rest of the keyboard shortcuts, https://www.youtube.com/watch?v=rfPwOtoGO4E. My dashboard looked like this: A complete working video and code are given below. Post Step 2: Create a New Channel by selecting Channel and entering the information requested in the image below. Mainly Wemos D1. You can install theThingerESP8266.hlibraryfrom the Arduino IDEs library manager. We MATHA ELECTRONICS will be back soon with more informative blogs. by mrc-core 24 May 2019, 16:23, #18 The runtime you're achieving seems low for the battery capacity, my greenhouse sensor runs 4 soil sensors via an ADS1015, 2 DS18B20, a BMP180 and a further ADS1015 for battery and light measurement via LDR. 41578645: EVENT: Contador_agua#Count=0.00. You'd be far better off waiting until you have data to report before you bring up the network. The Gerber file for all the PCBs is given below. thing["data"] >> [](pson& out){ Post Contohnya adalah dengan mengirimkan data penggunaan air dari sensor ke cloud sehingga bisa dengan mudah melihat hasilnya. I totally agree with Crandom's comments too. This means hook the pulse meter up to the RST and D7 or whatever, but prevent it from causing further resets (might need a transistor). Red, Yellow, and Black. Save my name, email, and website in this browser for the next time I comment. I will get into ESP-Now, as this seems to be the leanest method of communication, I will also look into using a GPIO pin instead of 5V to power the sensor, so that I can turn it off/on (better), Further, your input on the code (i.e. Water management is nearly impossible without measuring these characteristics. A consistent interval of 15 seconds can be used to send the same Flow Rate & Volume data to Thingspeak Server. { The sensor can be attached to the ESP8266s Vin and operates at 5 volts. In this activity, we will be reading and displaying the water flow meter on blynk using NodeMCU. I programmed a deepSleep into it as well. There are many methods for calculating water flow, as well as various types of water flow meters used to measure the amount of water flow in pipelines, but they are all too expensive. So you will be directed to NextPCB website. Antennas are designed to offer precise and reliable location information through the use of multi-band GNSS. Your email address will not be published. I'm new on using esp easy. Post Step 4: Select Private View and modify the display window as necessary. Well connect the NodeMCU ESP8266 Board to the YFS201 Hall Effect Water Flow Sensor. Serial.println("L"); I am getting the flow on the Serial Monitor but i wanted date and time stamp along with the flow inputs. Now Lets look at the Arduino IDE code for the ESP8266 water flow sensor. The water flow sensor works on the principle of the Hall Effect. I have a battery powered ESP8266 + temp/humidity sensor in each room in my house and I was only getting 10 days out of a D1 Mini + Si7021 temp/hum sensor powered by a 3.6V 600mAh LiFePo4 cell taking temp/humidity/batt voltage readings every 5 mins and then going into deep sleep. Then fill the form with the device ID, description, and Credentials or generate random credentials for your device and click on Add Device..
